DranSCADA
NEWSCADA Software From Dranetz!
DranSCADA is new HMI/SCADA software from Dranetz. Unlike other SCADA software, DranSCADA is built on a new, ultra-modern platform with a visually pleasing 2D/3D web based graphical user interface. Powerful communications and software interfaces, expandability, ease of use and an affordable price are just some of the other user benefits of DranSCADA. Just one look at DranSCADA makes you wonder how you used anything else before.
- Ultra modern, graphical SCADA software
- Web based and secure
- High quality, high fidelity zoom-able graphics
- Interactive 2D and 3D views
- Trending & alarming for any data point, including waveforms
- Native cloud support
- Open platform
- Customizable for any application
- Operating system agnostic (Windows, Linux, MacOS)
- For use with
- Dranetz HDPQ DataNode
- 61000 Family
- PQ3K, PQ5K
- AM Series Energy Meters
- Camille Bauer Energy Meters
- Any meter (Dranetz or other) using the Modbus & other protocols
- Non-power metering
DranSCADA is available in 3 editions- Basic, Professional and Enterprise. Below is a comparison of each.
| Standard | Professional | Enterprise | ||
|---|---|---|---|---|
| Communication Driver | ||||
| Modbus/TCP Client |
• | • | • | |
| Modbus/TCP Server | • | • | ||
| Modbus/RTU over TCP Client | • | • | ||
| OPC UA Client | • | • | ||
| OPC UA Server | • | • | ||
| OPC DA Client | • | • | ||
| OPC DA Server | • | • | ||
| BACnet Client | • | • | ||
| BACnet Server | • | • | ||
| SNMP Client | • | • | ||
| SNMP Server | • | • | ||
| DNP3 Client | • | • | ||
| DNP3 Server | • | • | ||
| IEC61850 MMS Client | • | • | ||
| IEC61850 MMS Server | • | • | ||
| RESTful API Client | • | • | ||
| RESTful API Server | • | • | ||
| DDE Client | • | • | ||
| DDE Server | • | • | ||
| UI Components | ||||
| One-Line (Single Line) w/ Live Data Overlay | • | • | • | |
| Imagery Background w/ Live Data Overlay | • | • | • | |
| Device Detail Screen | • | • | • | |
| Event/Alarm Screen | • | • | • | |
| Field-Customizable Dashboard/Report | • | • | • | |
| Export Dashboard/Report Screen as PDF | • | • | • | |
| User Management Console | • | • | • | |
| Role Based Access Control (RBAC) | • | • | • | |
| HTML Online Help | • | • | • | |
| One-Line (Single Line) w/ Live Animation | • | • | ||
| Imagery Background w/ Live Animation | • | • | ||
| Ethernet: Modbus/TCP, web server, NTP | • | • | ||
| 3rd-party Web App Embedding | • | • | ||
| Web Proxy for VNC | • | • | ||
| Device Log/Waveform Viewer | • | |||
| Interactive 3D Geospatial Screen | • | |||
| E-mail notification | • | |||
| Architecture/Technology | ||||
| Browser – Server (BS) | • | • | • | |
| HTTPS | • | • | • | |
| Secure WebSocket (wss) | • | • | • | |
| HTML5/CSS3 | • | • | • | |
| SVG | • | • | • | |
| WebGL (3D) | • | |||
| Operating System | ||||
| Windows XP SP3 and above | • | • | • | |
| Linux | • | • | ||
| Deployment/Installation | ||||
| On Premise | • | • | • | |
| Cloud | • | • | • | |
| Database Integration | ||||
| MySQL Client | • | • | • | |
| MySQL Server | • | • | • | |
| Microsoft SQL Client | • | |||
| Microsoft SQL Server | • | |||
| PostgreSQL Client | • | |||
| PostgreSQL Server | • | |||
| E-mail Integration | ||||
| POP3 Client (receive email) | • | |||
| SMTP Client (send email) | • | |||
